Bumper Hitch Light Cargo

Bumper Hitch Light Cargo

Available Lengths

  • 14', 16'

Available Paint Colors

Birch Metallic
Chestnut Metallic
Deep Blue Metallic
Gunmetal Metallic
Stealth Gray Metallic
Bright Red
Construction Yellow
Deep Green Metallic
Implement Orange
Super White
Bright Silver Metallic
Dark Gray Metallic
Deep Red Metallic
Jet Black

Available Pin Striping Colors

Silver
Gold
Black
Maroon
White
Green
Charcoal
Blue
Red

Estimated Weights

Length Axles Est. Base Weight
14' 2 x 3500# 3000#
16' 2 x 3500# 3220#

Standard Features

6’6” Inside Height
6'8" wide
32" Escape Door on Passenger Side
Torsion EZ Lube Axles 6 Bolt Hubs
20 ga. Galvanneal Exterior Sheeting
Spare Tire
Tube Frame
3/4" Marine Grade Plywood Flooring
Electric Brakes on all 4 Wheels
7/16" OSB Lined Wall - Full Height
Aluminum Tread Bright Gravel Guard
1 LED Dome Light with Interior Switch
Crossmembers, Uprights & Roof Bows on 24” Centers
2000# Top wind A-Frame Jack
L.E.D. Lights
Breakaway Battery Box with Charger and Tester
7-Prong Heavy Cord
2-5/16” Coupler
Steel Fold Down Rear Ramp (1500# max weight limit, includes torsion spring and cable)

Notes

  • STANDARD FEATURES SUBJECT TO CHANGE AT MANUFACTURERS DISCRETION
  • WEIGHTS MAY VARY ACCORDING TO OPTIONS


Optional Features

Fold Down Heavy-Duty Rear Ramp with Spring Assist (3000# max weight limit)
E-Track
Recessed, Flush Mount D-Ring, 6000 lb
Double Back Doors

Axles (Non-Standard Axles may increase lead time)

Single 6000# 8 Bolt Axle with 16" Radials
Single 7000# 8 Bolt Axle with 16" Radials
